Case Clamp CA-Series
特點(FEATURES)
FEATURES:
- High /low-speed transmission auto-switching. The clamper runs high speed into the setting position, and then automatically switches to a high torque motor to clamp the work-piece. It saves a lot of time and increasing production.
- With high rigidity and precision transmission structure, the work-piece can be placed nearby without worrying about structural damage.
- PLC & HMI control panel. Integrating operating functions and information at a glance.
- Single power source, low setup costs. Only electric drive, no air or hydraulic power, plugin, and ready for production.
- Step-less position setting. It can assemble from drawers to wardrobes.
.png)
規格(Specification)
|
Model |
CA-2000 |
CA-2500 |
|
Platen Size(L*W*H) |
2000*850*1900mm |
2500*850*1900mm |
|
Power |
1.5HP |
1.5HP |
|
Machine Size(L*W*H) |
3421*1067*2600mm |
3921*1067*2600mm |
|
Machine Weight |
2200Kg |
2500Kg |
